| Authentication Method: |
Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Compliant Standards: |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s |
| Device Type: |
Switch - 24 ports - L3 - Managed - stackable |
| Enclosure Type: |
Rack-mountable 1U |
| Features: |
Flow control, full duplex capability, Layer 3 switching, auto-sensing per device, IP-routing, DHCP support, auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, stackable, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Jumbo Frames support, Cisco StackWise Technology, Cisco EnergyWise technology, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN) |
| Flash Memory: |
32 MB Flash |
| Jumbo Frame Support: |
Yes |
| MAC Address Table Size: |
12K entries |
| Max Units In A Stack: |
9 |
| Performance: |
Switching capacity: 32 Gbps ¦ Forwarding performance: 38.7 Mpps |
| Ports: |
24 x 10/100/1000 + 4 x SFP |
| RAM: |
128 MB |
| Remote Management Protocol: |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, SSH, CLI |
| Routing Protocol: |
IGRP, BGP-4, IS-IS, RIP-1, RIP-2, HSRP, PIM-SM, static IP routing, PIM-DM, EIGRP for IPv6, OSPF for IPv6, policy-based routing (PBR), RIPng |
| Status Indicators: |
Port transmission speed, port duplex mode, bandwidth utilization %, system, RPS (Redundant Power Supply), link/activity |
| Subtype: |
Gigabit Ethernet |
