Authentication Method: |
RADIUS, TACACS+, Extensible Authentication Protocol (EAP), EAP-FAST |
Compliant Standards: |
IEEE 802.1D, IEEE 802.11b, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n (draft 2.0), CISPR 24, EN 61000-3-2, EN55022, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, AES, FCC CFR47 Part 15, VCCI V-3, ICES-003 issue 4 Class B, ICES-003 issue 4 Class A |
Connectivity Technology: |
Wireless, wired |
Data Link Protocol: |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n (draft 2.0) |
Device Type: |
Wireless router - 8-port switch (integrated) |
Enclosure Type: |
Desktop |
Encryption Algorithm: |
LEAP, Triple DES, MD5, AES, TLS, PEAP, TTLS, TKIP, WPA, WPA2, PKI, 128-bit AES, 192-bit AES, 256-bit AES, WEP |
Features: |
Firewall protection, auto-sensing per device, DHCP support, NAT support, MDI/MDI-X switch, VLAN support, auto-uplink (auto MDI/MDI-X), DiffServ support, MAC address filtering, Broadcast Storm Control, IPv6 support, Intrusion Prevention System (IPS), Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), MIMO technology, Spanning Tree Protocol (STP) support, Virtual Route Redundancy Protocol (VRRP) support, Wi-Fi Multimedia (WMM) support, Access Control List (ACL) support, Quality of Service (QoS), Link Fragmentation and Interleaving (LFI), Dynamic Multipoint VPN (DMVPN), DHCP server, Virtual Route Forwarding-Lite (VRF-Lite), DNS proxy, CleanAir technology, Bidirectional Forwarding Detection (BFD), DHCP relay, 2T3R MIMO technology, DHCP client, Hot Standby Router Protocol (HSRP) support, Ingress Layer 2 MAC Access Control Lists (ACLs), Call Admission Control (CAC), Flexible NetFlow (FNF) |
Flash Memory: |
256 MB (installed) / 256 MB (max) |
Frequency Band: |
2.4 GHz / 5 GHz |
Network / Transport Protocol: |
L2TP, RSVP, IPSec, FTP, DHCP, DNS, L2TPv3 |
RAM: |
512 MB (installed) / 1 GB (max) |
Remote Management Protocol: |
Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
Routing Protocol: |
OSPF, RIP-1, RIP-2, BGP, EIGRP, HSRP, VRRP, NHRP, IGMPv3, GRE, policy-based routing (PBR), WCCP, Bidirectional Forwarding Detection (BFD) |
Status Indicators: |
Port status, power |
